Delta 1600

  • Delta 1600

Energy Output:

Maximum Energy:

500 J

Display Resolution:

Based on Auto Range

Resolution:

1 J

Accuracy:

±1 % of reading ± 1



Load Resistance:

50 ohms ±1 %; non-inductive (< 1 μH)



Sampling Time:

20 uS

Measurement Time Window:

60 ms

Pulse Width:

60 ms



Patient Simulator:

Waveform Simulation:

ECG (NSR),ECG Rate: 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200, 220, 240. BPM

Accuracy:

± 1%

Waveform Amplitude:

ECG (AMP)

ECG Amplitude:

1.0, 2.0, 3.0, 4.0 mV

Accuracy:

± 5% peak to peak



Arrhythmia Selections: (Shock advisory waveforms)

Ventricular Fibrillation Coarse (VFBC)

Ventricular Fibrillation Fine (VFBF)

Ventricular Tachycardia (VTAC)

Atrial Fibrillation (AFIB)



Temperature Range:

Operating:

+15°C to +35°C

Storage:

0°C to +50°C.



Display:

Type:

LCD with LED backlit Graphics display



Power:

7.4 Volt Li-Ion Rechargeable Battery

100-230  VAC input 8.5V Battery Charger



Housing:

High impact ABS plastic enclosure



Dimensions:

D x W x H :10.25 x 6.25 x 2.5 Inch



Be prepared when you’re on the road with the durable Delta 1600. Keep track of your defibrillators’ performance in even the most remote locations. Our compact, battery-operated, precision analyzer works with all automated external defibrillators (AEDs); including Pulsed (Schiller) AEDs.

The Delta 1600 keeps you compliant with regulatory standards by measuring the discharged energy of the AED. The device also simulates several cardiac waveforms to ensure that the AED can consistently detect, analyze and audibly advise shock.

Dedicated function keys and a menu-driven display makes this device exceedingly intuitive to use. Its built-in load resistance of 50 ohms also replicates the impedance of the human body, ultimately providing you with realistic simulations.

The Delta 1600’s versatility and portability makes it a necessary tool for on-the-go and bench-top testing; it’s ideally suited for AEDs used in ambulances, police cars, sports stadiums, aircrafts, schools, malls, and other remote locations.

FEATURES

  • Compact, lightweight and easy-to-use
  • Auto Function – Eliminates multiple discharges
  • Large backlit graphics display
  • Multiple arrhythmia simulations
  • 7.4 Volt Li-Ion rechargeable battery
  • Includes a complete set of insulated banana jacks and a soft carrying case
  • 5 Year Warranty
